SAND AGGREGATE AND FILLERS TESTING MATERIALS AND EQUIPMENTS
Sand Pouring Cylinder equipment’s is used for determination of the dry density of compact, fine, medium-grained soils and for different layers not exceeding 50 cm thickness.
A circular hole is dug into the ground, all the soil from within it collected, weighed and dried and the hole back-filled with the standard uniform level sand or fine stones poured from a calibrated contain for calculating the volume of the complete hole.
Sand Pouring Cylinder (Small)
The equipment is suitable for field density estimation of fine and medium grained soils, as per IS:2720 (Part XXVIII).
It consists of:
- Sand Pouring Cylinder apparatus 115 mm internal dia with conical funnel and shutter.
- Calibrating Container apparatus, 100 mm inner dia and 150 mm deep with flange 50 mm wide.
- The measurement of the Metal tray 300mm square x 40 mm deep with a 100mm dia hole at the centre.
Sand Pouring Cylinder, (Large)
The equipment is suitable for estimation of field density of fine, medium and coarsegrained soils, as per IS:2720 (part XXVIII).
It consists of:
- Sand Pouring apparatus Cylinder Equipment’s, 215 mm internal dia, with conical funnel and shutter.
- Calibrating apparatus container 200 mm inner dia x 250 mm high with 75 mm wide flange.
- Metal tray 450 mm square x 50 mm deep with a 200 mm dia hole at the centre.
